Honeywell R8184G4009 Protectorelay 120 V Oil Burner Control
Skip to product information
Description
The Honeywell Protecto Relay provides intermittent ignition oil primary controls to operate the oil burner, oil valve (if desired) and the ignition transformer in response to a call for heat in oil burner systems. Manual trip safety switch lever and lockout indicator light is on the terminal strip which indicates system lockout. Has color-coded lead wires to make it easy for line voltage connections.
- Integral transformer powers low voltage control circuit
- Solid state flame-sensing circuit
- Enclosed safety switch with external reset button, safety switch must be manually reset after safety shutdown
- Temperature range of -40 - 130 degrees Fahrenheit
- Mounts on standard 4 inch x 4 inch junction box, select models may be mounted directly on burner housing
- Timing safety switch 45 seconds
- C554A cadmium sulfide flame detector and 24 VAC thermostat required
For more technical details and/or manufacturers product guides, email us.
Most orders leave our warehouse within 1 business day unless otherwise noted.
*Add this item to the cart to estimate shipping costs and any applicable taxes.
Features
- Voltage Rating:240 vac
- Domestic / Import:Domestic
- Maximum Temperature:130
- Depth:2-1/2 in.
- Electrical Ratings (Full Load):7.4 amps
- Height:4-3/8 in.
- Mounting Type:Direct Mount
- Packaging Type:Boxed
- Product Type:Oil Burner Control
- UL Listed:Yes
- Width:4-1/8 in.
- Application:For oil burner system
- Brand Name:Honeywell
- CSA Listed:Yes
- Electrical Ratings (Locked Rotor):44.4 amps
Reviews
Details
Product Details:
- Manufacturer:Honeywell
- Part Number:R8184G4009
- UPC:085267990127
- Sold in QTY:1
- Condition:New
- Country of Origin:United States
